Why Choose XINYE Planetary Cooking Mixers?
We set the "Zero-Burn" standard for industrial sauce and paste processing.
Find the Perfect Mixer for Your Recipe
Whether you are boiling fluid hotpot bases or cooking sensitive syrups, we have the perfect planetary structure to ensure even mixing and zero burning.
Hotpot Bases & Sauces
Gas/Induction+ Tilting Model
●️ Chili Sauce, Sambal, xo Sauce
High heat creates "Wok Hei" aroma. Scrapers prevent chili skin from burning.
Request Equipment Match
High Viscosity Purees
Steam+Tilting Model
●️ Curry Paste, Miso, Hummus
Gentle, constant heating prevents drying out. Powerful torque mixes oil & spices.
Request Equipment Match
Sweets & Candy
Thermal Oil/Induction+ Bottom Mix
● Caramel, Syrup, Custard
Precise temperature control is critical to prevent crystallization.
Request Equipment Match| High-Power Gas Heating Planetary Cooking Mixer | ||||||
| Volume | 100L | 200L | 300L | 400L | 500L | |
| Total Power | 3KW | 3KW | 3KW | 3.7KW | 3.7KW | |
| Mixing Speed RPM | 0-33 | 0-33 | 0-33 | 0-33 | 0-33 | |
| Gas pressure KPa | 4.5-6 | |||||
| Gas Consumption | LPG(KG) | 4-5 | 4-5 | 4-5 | 7-11 | 7-11 |
| NG(m³） | 5-6 | 5-6 | 5-6 | 8-12 | 8-12 | |
| Heating method | NG, LPG, Propane | |||||
| Diameter | φ800 | φ900 | φ1000 | φ1100 | φ1200 | |
| Overall Dimensions (mm) | 1250*1800*1550 | 1950*1500*1650 | 2000*1500*1700 | 2100*1550*1700 | 2200*1600*1700 | |
| Max Load Capacity | 60 | 120 | 170 | 230 | 280 | |
| Induction Heating Planetary Cooking Mixer | ||||||
| Volume | 100L | 200L | 300L | 400L | 500L | |
| Power | Mixing Power | 1.5KW | 1.5KW | 1.5KW | 2.2KW | 2.2KW |
| Heating Power | 20KW | 20KW | 30KW | 40KW | 50KW | |
| Mixing Speed RPM | 0-33 | 0-33 | 0-33 | 0-33 | 0-33 | |
| Diameter | φ800 | φ900 | φ1000 | φ1100 | φ1200 | |
| Overall Dimensions (mm) | 1550*2000*1650 | 1700*2100*1700 | 1800*2200*1750 | 1900*2200*1800 | 1900*2200*1800 | |
| Max Load Capacity | 60 | 120 | 170 | 230 | 280 | |
| Steam Heating Jacketed Planetary Cooking Mixer | ||||||
| Volume | 100L | 200L | 300L | 400L | 500L | |
| Total Power | 3KW | 3KW | 3KW | 3.7KW | 3.7KW | |
| Mixing Speed RPM | 0-33 | 0-33 | 0-33 | 0-33 | 0-33 | |
| Working Pressure | 0.3MPa | |||||
| Diameter | φ800 | φ900 | φ1000 | φ1100 | φ1200 | |
| Overall Dimensions (mm) | 2000*1500*1650 | 2000*1500*1700 | 2100*1650*1700 | 2100*1800*1700 | ||
| Max Load Capacity | 60 | 120 | 170 | 230 | 280 | |
| Automatic Thermal Oil Planetary Cooking Mixer | ||||||
| Volume | 100L | 200L | 300L | 400L | 500L | |
| Motor Power | Gas heating with thermal oil | 3KW | 3KW | 3KW | 3.7KW | 3.7KW |
| Electric heating with thermal oil | 30KW | 30KW | 39KW | 40KW | 40KW | |
| Mixing Speed RPM | 0-33 | 0-33 | 0-33 | 0-33 | 0-33 | |
| Diameter | φ800 | φ900 | φ1000 | φ1100 | φ1200 | |
| Overall Dimensions (mm) | 2000*1450*1600 | 2000*1500*1650 | 2000*1500*1700 | 2100*1450*1700 | 2100*1600*1700 | |
| Max Load Capacity | 60 | 120 | 170 | 230 | 280 | |
Choose Your Planetary Mixer by Heating Source
Different recipes require different heat. We offer four distinct heating configurations to match your process, energy costs, and precision requirements.
Automatic Thermal Oil Planetary Cooking Mixer
Induction Heating Planetary Cooking Mixer
High-Power Gas Planetary Cooking Mixer
Steam Jacketed Planetary Cooking Mixer
Planetary Bottom Mixing Cooking Pot
Engineering the "Zero-Burn" Standard
We don't just build kettles; we engineer the perfect combination of a seamless stamped body and tilted planetary agitation to solve the industry's toughest "burn-on" and emulsion challenges.
- One-Step Stamped Kettle Body
Hand-welded kettles have uneven surfaces causing burn-on. We use heavy hydraulic stamping to form the kettle in one step, ensuring absolute roundness so the scrapers maintain 100% seamless contact with the bottom.
- Tilted Planetary Agitation
Standard mixers leave unmixed edges. Our unique inclined-shaft system drives the agitators to revolve and rotate simultaneously. This non-integer transmission creates a massive 3D folding action, delivering flawless emulsions for delicate sauces.
Build Your Sauce Production Line Today!
Share your recipe details and production goals. Our engineering team will help you select the ideal heating source (Gas, Steam, or Induction) to ensure perfect emulsions and absolutely zero product waste.
